A06B-6110-H011
Fanuc A06B-6110-H011 Power Supply Module. Produced between 2004 and 2008 this model PSM-11i ALPHA i supply module powers the ai drive series of amplifiers. Consisting of servo amplifier modules and spindle amplifiers. Rated at 13.2kW can power similar rated Fanuc spindle module and a couple of servo amps; or smaller spindle amp and more Fanuc ai servo modules. Alternatively it can work in tandem with other aiPS power modules.
As part of the 200V AC Fanuc alpha i drive series; this amplifier is from the first generation of ai amplifiers. Together with its powered spindle/servo drive configuration; they were controlled by various CNC controls from late 16i/18i/21i model B and early 0i A/B/C systems. This drive includes the power board A16B-2203-0641 not supplied seperate.
DNC offer several services for the 13.2kW version of this drive. Inclusive of service exchange; which we have been offering since the 1990’s on Fanuc. Currently this drive is in stock available exchange. Alternatively 24 hour repair turnaround is the norm. Fault diagnosis and testing is extensively supported. Further we also supply fuses, fans and transistors modules if required for these drives.
Contact us for prices and availability via phone or email. If you are unsure whether your aiPS-11 drive is in fact faulty or not; then consult our ai power supply module alarm codes.
