A06B-6124-H209
Fanuc A06B-6124-H209 servo amplifier module. This SVM 80/80HVi drive is part of the ALPHA i family of drive and motors. As a dual channel amplifier from the 400VAC series of ai modules its fitted on many CNC machine tools. The drive is made of modular plastic framing the wiring pcb A16B-2203-0814 and A20B-2101-004x dual axis control board. Neither boards is available seperate from the complete drive.
The A06B6124H209 servo amplifier normally drives one of the following in any axis combination: a22/4000HVi, a30/4000HVi, a40/4000HVi. This drive is the largest dual channel amplifier from the entire 400VAC series. At DNC we also offer Daito fuses, Fanuc fans (internal and external) and IPM transistor modules.
This drive is normally in stock. At DNC preference is supply on an service exchange basis (your part must be complete, economically repairable and NON interfered with). If the price of exchange is prohibitive then we also clean, inspection and testing on our test rigs. We also offer a 24 hour repair turnaround as standard; assuming your part is indeed economically repairable. Usually we always have many options to get around problems other non specialist companies cant get around.
Consult our Fanuc ai servo amplifier module alarms page if you are unsure your A06B-6124-H209 is indeed faulty or not. Contact us if you require information on prices and avaibility of this aiSV2 80/80HV servo module.
