A06B-6078-H106
Fanuc A06B-6078-H106 ALPHA Spindle Module. This SPM-5.5 IV amplifier is uses the type 4 interface supporting multiple sensor feedback to the CNC control system. Rated at 27amp with an output of 6.8kW it would normally power and control model a3 or aP8 ALPHA spindle motors. This will not normally be twinned with high speed a3 motors such as the a3/12000.
This drive is fitted with a A16B-2202-0681 power board and A16B-2202-043x series spindle control card. Neither board are available seperate from the complete drive. Normally these amplifiers are found on small machines or running as a sub spindle on bigger applications.
A06B-6078-H106 is in stock and available immediately on a service exchange basis. Alternatively we offer extensive diagnosis, fault inspection and testing facilities and repair capabilities second only to the OEM. Repair turnaround is normally 24 hours.
Consult our Fanuc ALPHA spindle alarm pages to reference the alarm code on the front of your SPM-5.5 amplifier. At this point always go through matters with your CNC service engineer.
For more information about exchange prices, repair and test turnaround and avaibility contact us via phone or email.
