A06B-6102-H222#H520
Fanuc A06B-6102-H211#H520 spindle module. Also known as GE Fanuc SPM-22 type I interface standard specification supporting spindle HRV control. Rated at 25.2kW output and capable of driving model a22/8000 or high speed a15 motors or aP30 series spindle motors.
As part of the 3rd generation of 200VAC ALPHA spindle drives this amp has #H520 software hence A06B-6102-H222 with the #H520. Comprised of a power PCB A20B-1006-0487 with the type 1 interface control PCB A16B-2203-0502. None of the boards or software is available seperate to the whole drive.
The SPM-22 type 1 amplifier is in stock avialble for exchange or surplus if stock permits. Alternatively we offer extensive closed loop testing and inspection facilities for this spindle drive. Including cleaning, fault finding of intermittent faults, replacement parts such as transistors, fuses, and fans.
If you are unsure your SPM-22 ALPHA spinde is at fault then check the dual 7 segment LED display on the front of the drive and consult our ALPHA spindle module alarms.
Contact us on +44 (0)1793 615356 for further information on stock, prices for various services beyond listed on this page. Turnaround times on testing and repair or rebuild services dependent on the condition of your SPM-22 spindle amplifier.
