A06B-6104-H275
Fanuc A06B-6104-H275 ALPHA Spindle Module (high voltage). This is the largest 400VAC series HV spindle amplifier module which runs on very large CNC machine tools. Using the Type 1 spindle interface with no JY5 sensor connector; it’s normally paired with massive HV spindle motors and matching PSM.
These drives series along with the 6102 (200VAC) series all had #H520 software. This meant as long as you ordered the correct type i.e. Type 1 or 2 then you did not need to worry about ROM software version as the instruction set covered most others.
At DNC we stock these SPM-75HV amplifiers and can supply on an exchange basis or surplus outright with warranty. Alternatively we offer full testing and repair facilities to analize fault codes and errors on the spindle module. We have dedicated high voltage testing facilities for this drive and large motors.
We know a lot about these drives and the common faults that normally present on these modules. However some are vague and require far more investigation by an on site CNC service engineer. For a simple break down of the alarms present on the A06B-6104-H275#H520 then check our Fanuc spindle amplifier alarm page.
Common alarms on this spindle amplifier modules 1, 11, 12, 19, 20, 31, 33, 51 and so on. Contact us if you need information pricing on exchange, test and repair options or stock availability.
