A20B-1000-0560
Fanuc A20B-1000-0560 AC axis control board. This PCB is fitted upon single axis analogue velocity control units. Fittted on tens of thousands of machines throughout its release window prior to digital servo drives. Normally found with CNC controllers such as analogue 10 and 11 controls and series 0-A systems.
This control card would normally front drives including the H002, H005, H006, H102, H103, H104, H113, H303 and H304. There are six versions of this control board with completely different layouts and setups. The suffix code after A20B10000560 includes a letter from A to F i.e. /13F.
Hence before ordering one of these boards please check the full 15 digit part number on this board as they are not interchangable.
