A06B-6057-H004
Fanuc A06B-6057-H004 AC servo amplifier. Single channel axis drive using digital interface between itself and late system 10 or 11 and 0 model A/B controls. This drive along with the rest of the 6057 series of AC servo amplifier unit is Fanuc’s first AC series of digital servo drives.
The H004 like most of the 6057 series was built using a single channel PCB as interface board atop an anodised metal frame. Digital servo control PCB is A20B-1200-0670 (available seperate). Found powering model 0 and 5 AC servo motor fitted on many different size and complexity of machines.
Carrying these drives in stock for over 20 years; theres not much we don’t know about them. Hence offer extensive testing, repair, rebuild capabilities. Our test and repair turnaound is 24 hours. If you require a A06B-6057-H004 faster; then take advantage of our stocked service exchange available to ship.
Unsure whether your digital model 0 drive is faulty; check which LED is lit on the front drive PCB and click on proceeding link for AC servo amplifier alarms.
Contact us on +44 (0)1793 615356 for further information on stock, prices for various services beyond listed on this page. Turnaround times on testing and repair or rebuild services dependent on the condition of your 0/5 servo unit.
