A06B-6063-H212
Fanuc A06B-6063-H212 AC spindle drive. As part of the second generaiton of serial series AC spindle drive its one of the mid sized yellow plastic frame drive using serial interface fibre optic connection too 0-C/D and 16/18/21 controls.
As this drive is 2rd generation serial series its software A06B6063H212#H510 it superceeds earlier AC serial spindle drives assuming matched electrical ratings.
Not being the largest drive of the 6063 series the H212 is still powerful driving AC model 12S or 15P spindle motors. At the back is the power components such as capacitors, contactors, transistors on a large heatsink as well other high powered devices. Next is the wiring PCB A20B-1003-012x (not available seperately) which directs the power to the blue connectors.
Similar to earlier AC spindle drives from Fanuc this spindle unit has one serial spindle control PCB acting as both control and firing circuit A20B-1003-0920 (available seperately).
At DNC we have supported these serial spindle drives since our inception. As a Fanuc specialist repair facility we have repaired hundreds of 6063 series drives over the years and supplied this model to many well known manufacturers in the Automotive and Aerospace industries. Currently we have this drive in stock; when we don’t we can rely on group stocks to back us up.
Contact us on +44 (0)1793 615356 for further information on stock, prices for various services beyond listed on this page. If you are unsure if your unit is faulty then check our Fanuc serial spindle alarms page or contact us.
