A16B-2200-0360
Fanuc A16B-2200-0360 axis board. This peripheral PCB plugs into the 0-C or 0-D master board and gives 3 or 4 channels of 32bit servo control. Known as the 3/4 axes card it normally is supplied in its 3 axis configuration then the end user will move their LSI across for 4th channel.
At the point of manufacturer Fanuc was in coloboration with GE hence creating GE Fanuc brand which supplied CNC throughout Europe. The A16B22000360 board is non-surface mount PCB.
As the second release of axes boards for the 0 model C controls; this 32bit board controls digital servo amplifier units. Namely S series servo amplifier units and C series servo drives.
Certain alarms on series 0-C that can be caused by this card or the master PCB. Namely alarms 914 and 920 being the main alarms. Consult the series 0 alarms for 0C faults.
If unsure of the alarms on your Fanuc 0-C control then we can test this board and the complete 0-MC, 0-MD, 0-TC, 0-TTC, 0-TD, 0-TTD control system.
Contact us on +44 (0)1793 615356 for further information on stock, prices for various services beyond listed on this page. Turnaround times on testing and repair or rebuild services dependent on the condition of your 32 bit 3/4 Axis 0-C axes board.
